TK-8360E
UHF FM mobiele zendontvanger - voldoet aan de ETSI-normering
Niet meer beschikbaar
Belangrijkste Eigenschappen
| Frequency Range: 400-470 MHz |
| 128 Channels/128 Zones |
| 25 Watts RF Output |
| Emergency Mode |
| QT & DQT Signalling plus DTMF PTT ID |
| 5-Tone Encode/Decode |
| Electronic Serial Number |
| MDC-1200 Signalling (requires special license ID) |
| D-Sub 15 pin Interface Connector |
| Requires Optional Microphone |
Geleverd met
| Gelijkstroomkabel | Ja |
| Zekering | Ja, 10 A |
| Handleiding | Ja, Engels, Spaans, Duits, Frans, Nederlands, Italiaans, Turks & Grieks |
| Montagebeugel | Ja |
| Schroevenset | Ja |
Eigenschappen
Eigenschappen "FleetSync Signalling"
| External-device Switching | Ja, External devices can be switched (via the AUX output) on receipt of a status ID code |
| Paging Call Function | Ja |
| PTT ID Digital ANI | Ja |
| Selective Calling | Ja |
| Short/Long Text Messages | Ja |
| Status Messaging | Ja, Status messages are pre-programmed 2-digit codes from 10 - 99 (numbers 80 - 99 are reserved for special messages). Up to 15 messages can be stored in stack memory. |
Eigenschappen "MDC1200 Signalling"
| Emergency Encode/Decode | Ja |
| PTT ID Encode/Decode | Ja |
| Radio Check Decode | Ja |
| Stun/Revive Decode | Ja |
Opties
| Internal GPS Board | Yes - NMEA 0183 V2 compatible |
| "Molex" interface | Via KCT-60M Cable |
| Optionele stembegeleiding & opname-eenheid | Ja |
Applicable Standards
| R&TTE: EN300 086, 300 113, 300 219, 301 489 | Ja |
| EN60065, 60950-1, 60215 | Ja |
| Factory Quality Certification and Location | ISO 9001. Manufactured in Singapore |
| For use in the EU | Ja |
| IP54 | Ja |
| MIL-STD 810 C/D/E/F/G | Ja |
Technische Specificaties
| Frequency Range - E Type | 400-470 MHz |
| Number of Channels | 128 |
| Number of Zones | 128 |
| Channel Frequency Spread | 70 MHz |
| Channel Spacing - Analogue - Wide/Mid/Narrow | 25 kHz/20 kHz/12,5 kHz |
| Antenna Impedance - 50 Ohm | Ja |
| Current Drain | Standby: 0.3 A
Receive: 1.0 A Transmit: 8.0 A |
| Frequency Stability | ± 2,5 ppm (-30 °C to + 60 °C) |
| Operating Temperature Range | -30 °C to + 60 °C |
| Operating Voltage | 13.2 V DC ± 15% |
| PLL Channel Steps | 5.0 kHz/6.25 kHz |
| Dimensions (WxHxD) | 160 x 43 x 136 mm (Projections not included) |
| Weight (net) | 1.2 kg |
Specificaties "Receiver"
| Adjacent Channel Selectivity | Wide/Mid/Narrow - 70/70/60 dB |
| Audio Output | 4 W with less than 5% distortion |
| Intermodulation | 67 dB |
| Sensitivity - EIA 12 dB SINAD | 0.28 µV at 25 kHz 0.28 µV at 20 kHz 0.35 µV at 12.5 kHz |
| Spurious & Image Rejection | 70 dB |
Specificaties "Transmitter"
| RF Power Output (High/Low) | 25 W / 5 W |
| FM Noise (EIA) | Wide/Mid/Narrow: 45/45/40 dB |
| Microphone Impedance | 600 Ohm |
| Modulation Distortion (Wide/Mid/Narrow) | Less than 3% |
| Modulation Limiting | ± 5.0 kHz at 25 kHz
± 4.0 kHz at 20 kHz ± 2.5 kHz at 12.5 kHz |
| Spurious Emission (EN) | -36 dBm ≤ 1 GHz -30 dBm > 1 GHz |
